Tektronix DPO4054B
4 Ch 500 MHz Digital Oscilloscope
The Tektronix DPO4054B 4-channel Digital Phosphor Oscilloscope with 500 MHz bandwidth and 2.5 GS/s sample rate guarantees the performance you need, to see fast-changing signal details. The Tektronix DPO4054B analyzes up to 20 analog and digital signals to identify and diagnose an anomaly quickly and to simplify and speed debug in complex designs. With bandwidths up to 350 MHz and a minimum of 5X oversampling on all channels, the DPO4054B helps capture extended windows of signal activity while keeping fine timing resolution.
The Tektronix DPO4054B has Wave Inspector controls for rapid waveform navigation, automated serial and parallel bus analysis, limit and mask testing, and automated power analysis. Offering the most complete visualization of signals, the DPO4054B includes four low-capacitance probes for accurate signal capture.
Tektronix DPO4054B - Features and Specifications:
- 4 analog channels
- Bandwidth of 500 Mhz
- 20 megapoint record length on all channels
- Maximum waveform capture rate of > 50,000 wfm/s
- Advanced Triggers suite
- 10.4 inches XGA Color Display
- USB Host and Device Ports for storage, printing and connectivity
The Tektronix DPO4054B is available for rent or lease from TRS-RenTelco with 24/7 customer support.
Contact us and request a quote today.
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Marker Set
Qty: 1 -
Cord Power
Qty: 1 -
Hook Tip
Qty: 4 -
Ground Lead
Qty: 4 -
Accessory Pouch
Qty: 1 -
Cover Front
Qty: 1 -
Probe TPP0500 Or TPP0500B
Qty: 4 -
USB Drive with Software and Manuals
Qty: 1
