Keysight Technologies N6781A
20/6V, 1/3A, 20W Source/Measure DC Power Supply Module
The Keysight (formerly Agilent) N6781A is a 2-quadrant source/measure unit (SMU) that can accurately capture the power consumption of portable, battery-powered devices from 20 W to 80 W. Designed specifically for battery drain analysis, the N6781A has seamless measurement ranging that reduces the challenges of measuring dynamic currents. Whether the device-under-test (DUT) is an e-Book reader, MP3 player, mobile phone, or pacemaker, the N6781A allows engineers to accurately measure dynamic currents without any anomalies or disruptions to the measurement. The combined features of seamless measurement ranging, programmable output resistance, and auxiliary DVM makes the N6781A the device with the best set of advanced features on the market for battery drain analysis to enhance battery life. When used with the 14585A Control and Analysis software, the N6781A becomes an even more powerful battery drain analysis solution, offering additional insights into your measurements.
Keysight N6781A ? Key Features and Specifications:
- Provides excellent battery life with understanding into your device's power consumption
- Safe usage and glitch-free operation with the DUT despite output and measurement range changes
- 2-quadrant operation
- Measure all modes of operation simultaneously
- Exceptional transient response keeps voltage or current stable during high-speed load changes
- Provides scope, data logger, and complementary cumulative distribution function (CCDF) statistical analysis data
Get the Keysight N6781A for rent or lease at TRS-RenTelco with 365-day customer support.
Contact us to learn more or request a quote today.
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Jumper Assembly
Qty: 2 -
Connector Plug 4-Position
Qty: 1 -
Screw M3 x 0.5 6 mm TORX #10
Qty: 2 -
Kit Connector and Jumper
Qty: 1 -
Adapter Kit
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Keysight Technologies N6781A Spec Sheet
