Keysight Technologies E36313A
6 V, 10 A and 2 x 25 V, 2 A, 160 W DC PS, triple-output,
Make highly accurate voltage and current measurements with the Keysight (formerly Agilent) E36313A triple output power supply.
The E36313A power supply provides high current up to 10A for higher power applications. This power supply offers clean and reliable power, thanks to its low output ripple/noise and superior line and load regulation of 0.01 percent.
The Keysight E36313A features outstanding benchtop capabilities, such as low acoustic noise, auto series and parallel connections, and front and rear output terminals, giving you the performance of system power supplies while being affordable. The E36313A offers advanced characterization for data logging, output sequencing, LIST mode, and low current range measurements.
Keysight E36313A Features and Specifications:
- Power output: 160W
- Series mode voltage: 50V
- DC output rating (0 degrees to 40 degrees C)
- 0V to 6V, 0A to 10A
- 0V to 25V, 0A to 2A
- Load regulation plus/- (percent of output offset)
- Voltage: < 0.01 percent 4 mV
- Current: < 0.01 percent 500 uA
- Line regulation plus/-< 0.01 percent 1 mV
- Current: < 0.01 percent 500 uA
The Keysight (formerly Agilent) E36313A triple output power supply is available for rent or lease at TRS-RenTelco with 24/7 support. To know more or to get a quote, call us at 800.874.7123.
(percent of output offset)- Voltage:
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
USB Software
Qty: 1 -
Connector 4-Terminal 3.5 mm Pitch. Installed on some units.
Qty: 1 -
Connector 4-Terminal 5 mm Pitch. Installed on some units.
Qty: 1 -
Connector 8-Terminal 5 mm Pitch .Installed on some units.
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, GPB
See Configuration Details
-
GPB
GPIB Interface Module for E36312A, E36313A - installed
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
USB Software
Qty: 1 -
Connector 4-Terminal 3.5 mm Pitch. Installed on some units.
Qty: 1 -
Connector 4-Terminal 5 mm Pitch. Installed on some units.
Qty: 1 -
Connector 8-Terminal 5 mm Pitch .Installed on some units.
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Keysight Technologies E36313A Spec Sheet
