Doble Engineering F6150SV
Three Phase Relay Test Set
The Doble Engineering F6150SV is a versatile, all-in-one solution for testing protection relays and schemes, capable of performing the simplest through the most complex tests. Designed to test an individual component or an entire scheme, the F6150SV is the proven solution to assess protection system performance for analog testing of 1A and 5A protection devices.
Here are some of the main features of the Doble Engineering F6150SV Power System Simulator:
- IEC61850 testing with 3 packets of 9-2 LE communication protocol and station bus messaging - one fiber and one copper IEC61850 communication port
- Wi-Fi Capable
- Standard relay calibration and verification testing of High Burden and Microprocessor relays
- Increased amplifier power output and ranges (enhanced ratings)
- Protection scheme testing using State Simulation and Transient testing: powerful models made available in Protection Suite Software
- Metering at 0.2 class CTs and Transducers
- End to End testing of Communication Based Schemes with GPS time syncing
- 12 Source, (6-Voltage, 6 Current), configurable for Bench testing and proof of concept testing for complicated relaying schemes
The Doble Engineering F6150SV is available for rent or lease at TRS-RenTelco. Our experienced team of metrologists and technicians calibrate each product to stringent standards in our 50 GHz ANSI/NCSL Z540-1 compliant laboratory. Contact us and request a quote today.
- Configurations
- Resources
CASE, F6005, F6810, F6910
See Configuration Details
-
F6810
High Power Source
-
F6910
Simulator Control Module
-
F6005
Enhanced Ratings
-
CASE
Transit Case
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable Adapter #4 R Lug - 3 x 4 mm
Qty: 2 -
Bag
Qty: 1 -
Cable USB-A - USB-B
Qty: 1 -
Cover Front
Qty: 1 -
Cable Ethernet CAT5e RJ45 - RJ45 At least 6 ft. (AP 2000-1371)
Qty: 1 -
Case Transport for F6000
Qty: 1 -
Connector Ground Breakout for AC Line
Qty: 1 -
Adapter Kit
Qty: 1 -
Cable Kit
Qty: 1 -
Cable Kit
Qty: 1 -
Cable Kit
Qty: 1 -
Cable Kit
Qty: 1 -
Cable Kit
Qty: 1 -
Cable Fiber
Qty: 1 -
Cable Fiber
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1 -
Cord Power 15 A
Qty: 1
