Associated Research 3765
5 kV AC/6kV DC Hipot Tester
The Associated Research 3765 is a 5KV AC and 6KV DC Hipot tester with an enhanced graphic LCD. It can be used as a bench-top instrument or controlled through entry-level automation with an RS-232 interface or with enhanced PLC Remote Control.
Features and Specifications
- Protection from shock hazards with SmartGFI safety circuit
- Min. and max. Trip settings for accurate testing
- Simple remote operation through PLC Remote Control
- Remote Safety Interlock to prevent high voltage from being activated without the interlock enabled
- Forms a complete test system by interconnecting with the HYAMP III Associated Research Ground Bond Tester
- Patented VERI-CHEK feature guides users through steps to validate the instrument's operation
- Patented CAL-ALERT feature alarms the operator if the tester is due for re-calibration
- Check basic continuity with the built-in adjustable Continuity test
- Store and recall test parameters with 10 Memories (3 Steps per memory)
- Frequency: 50/60 Hz plus/minus 5%
- Voltage: 115/230 VAC plus/minus 10%
- Fuse: 3.15 A, fast acting 250 VAC
- DC Ripple less than and equal to 5% Ripple RMS at 6KVDC @ 7.5mA
- Mechanical: Bench or rack mount with tilt-up feet
- Interface: RS-232 interface standard for entry-level automation
- Dimensions: (W x H x D) 8.46 x 3.5 x 14.57 in.; (215 x 89 x 370 mm)
The Associated Research 3765 is available for rent or lease from TRS-RenTelco with 365-day customer support.
- Configurations
- Resources
- FAQsAI
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cable High Voltage
Qty: 1 -
Cord Power
Qty: 1 -
Lead Standard HiPot Return 5 ft
Qty: 2 -
Cable DB 9(f) - DB 9(f)
Qty: 1 -
Connector Interlock (installed in some units )
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1 -
Connector Interlock label
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Associated Research 3765 Manual
Associated Research 3765 Spec Sheet
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the Associated Research 3765?
The Associated Research 3765 is a part of the Hypot® III series, a benchtop Dielectric Withstand Tester that features AC/DC Hipot testing with ground continuity check. It is designed for a wide range of applications including safety testing of electrical and electronic devices.
What are the key features of the 3765?
Key features include RS-232 interface for automation, patented SmartGFI® safety circuit, 10 memories with 3 steps per memory for storing and recalling test parameters, PLC remote control for simple operation, VERI-CHEK® feature to validate the instrument's operation, CAL-ALERT® for recalibration notifications, and interconnectivity with an Associated Research Ground Bond tester to form a complete test system.
What are the output ratings for the 3765 AC/DC Hipot Tester?
The 3765 offers a 5000 V @ 20 mA AC and 6000 V @ 7.5 mA DC output rating, providing versatile testing capabilities for a wide range of products.
Can the 3765 be used for ground continuity testing?
Yes, the 3765 includes a built-in adjustable continuity test for checking basic continuity, ensuring the integrity of ground connections in electrical equipment.
What are the voltage setting ranges and accuracy for the 3765?
Voltage setting ranges for AC testing are from 0 to 5.00 KV, and for DC testing from 0 to 6.00 KV, with a resolution of 0.01 KV and an accuracy of ± (2% of setting + 5 V).
How does the 3765 handle arc detection?
The 3765 includes a digitally controlled arc detection circuit that allows the operator to program sensitivity levels for detecting arcs, enhancing the safety and accuracy of tests.
What safety features does the 3765 incorporate?
Safety features include the SmartGFI® safety circuit to protect the operator from shock hazards, remote safety interlock to prevent high-voltage activation without the interlock enabled, and compliance with relevant safety standards.
What kind of remote control capabilities does the 3765 offer?
The 3765 provides PLC remote inputs and outputs for simple remote operation, allowing integration into automated test setups.
How is the 3765 calibrated and verified?
The 3765 is calibrated using standards traceable to the National Institute of Standards and Technology (NIST), ensuring accuracy and reliability in measurements. Calibration is controlled by software, and adjustments are made through the front panel keypad in a restricted access calibration mode.
What are the physical dimensions and weight of the 3765?
The 3765 measures 8.46 x 3.5 x 14.57 inches and weighs approximately 20.96 lbs, making it suitable for benchtop use in various testing environments.
